Article number | GEG260ES-2RS - GE260FO-2RS - GEH260ES-2RS |
B (Inner ring width) | 205 mm |
Basic load ratings dynamic | 3570 kN |
Basic load ratings statisch | 17850 kN |
C (Width of outer ring) | 120 mm |
CN Radial internal clearance | 0,110 - 0,214 mm |
Color | Metaal |
d (Bearing bore) | 260 mm |
D (Outer diameter outer ring) | 400 mm |
Material | steel / steel |
Model | Gewrichtslager radiaal onderhoudsplichtig |
Norm | DIN ISO 12 240-1 G |
Seals | Yes |
Tilting angle | 15 α° ≈ |
Dimensions | 260 x 400 x 120 x 205 mm |
Dimensions and weight | |
Weight | 82.44 Kg |
Dimension | 260 x 400 x 120 x 205 mm |
